Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheremovalprocedure,goto“Completingthepartsreplacement”onpage170
.
InstallingorremovingtheThinkServerTrustedPlatformModule
ThistopicprovidesinstructionsonhowtoinstallorremovetheThinkServerTrustedPlatformModule
(hereinafterreferredtoastheTPM).
TheTPMisasecuritychipdesignedbytheTrustedComputingGroup(TCG)toprovideahardwaremethod
ofdataencryption.Itstorespasswords,encryptionkeys,anddigitalcertificatestohelpprovidesecurity
solutionsandprotectthecomputer.YoucanpurchaseaTPMoptionfromLenovo.
InstallingtheThinkServerTrustedPlatformModule
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage73.
ThistopicprovidesinstructionsonhowtoinstalltheTPM.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•UseanydocumentationthatcomeswiththeTPMandfollowthoseinstructionsinadditiontothe
instructionsinthistopic.
•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationinthistopic.
ToinstalltheTPM,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Iftheserverisinstalledinarackcabinet,removetheserverfromtherackcabinetandplaceitonaflat,
clean,andstatic-protectivesurface.SeetheRackInstallationInstructionsthatcomeswiththeserver.
3.Removetheservercover.See“Removingtheservercover”onpage75.
4.LocatetheTPMconnectoronthesystemboard.See“Systemboardcomponents”onpage38.If
thereisanyPCIExpresscardinstalledontherisercardassembly1,itmightblockyouraccesstothe
TPMconnectoronthesystemboard.Inthiscase,youneedtoremovethecoolingshroudandthen
carefullylifttherisercardassembly1upsothatyoucanaccesstheTPMconnector.Youdonotneedto
disconnectanycablesfromthePCIExpresscardorcompletelyremovetherisercardassembly1.
5.Touchthestatic-protectivepackagethatcontainstheTPMtoanyunpaintedsurfaceontheoutsideof
theserver.Then,taketheTPMoutofthepackage.
Note:CarefullyhandletheTPMbyitsedges.
108ThinkServerRD340UserGuideandHardwareMaintenanceManual
