6.InserttheTPMintotheTPMconnectoronthesystemboard.
Figure67.InstallingtheTPM
7.Ifyouhavelifteduptherisercardassembly1,reinstallitintothechassis.See“Replacingtheriser
cardassembly1”onpage155.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage184.Then,youcan
configuretheTPMfunctionintheSetupUtilityprogram.See“ConfiguringtheTPMfunction”onpage64.
RemovingtheTPM
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage75.
ThistopicprovidesinstructionsonhowtoremovetheTPMiftheserverhasoneinstalled.
Chapter6.Installing,removing,orreplacinghardware111
