Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•ToconfigureRAID,goto“ConfiguringRAID”onpage70
.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage184
.
Replacinga2.5-inchsolid-statedrivefroma3.5-inchhard-disk-drivebay
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage75.
Thistopicprovidesinstructionsonhowtoreplacea2.5-inchsolid-statedrivefroma3.5-inchhard-disk-drive
bay.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Toreplacea2.5-inchsolid-statedrive,dothefollowing:
1.Locatetheappropriatehard-disk-drivebay.See“Servercomponents”onpage31.
2.Pressthereleasebutton1toopenthehandleofthe3.5-inchdrivebracket.
MEM 1
PSU 1 2
1 2 3 4 5 6 7 8
MEM 2
1 2 3 4 5 6 7 8 9 10
CPU 1 2
1 2 3 4 5 6 7 8 9 10
ID
PSU
Mem
CPU
Figure92.Openingthehandleofthe3.5-inchdrivebracket
