Frontviewoftheserver
Thistopicprovidesinformationtohelpyoulocatethepartsonthefrontoftheserver.
Thefrontviewoftheservervariesbymodel.Theillustrationsinthistopicshowtheserverfrontviews
basedonthesupportedharddiskdrives:
•Frontviewofservermodelswith3.5-inchharddiskdrives
•Frontviewofservermodelswith2.5-inchharddiskdrives
Notes:
•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
•Theterm“2.5-inchhot-swapharddiskdrives”or“2.5-inchharddiskdrives”hereinafterreferstoallthe
supportedtypesof2.5-inchharddiskdrives,includingthesolid-statedrives.
Frontviewofservermodelswith3.5-inchharddiskdrives
Thefollowingillustrationshowsthefrontviewofservermodelswith3.5-inchharddiskdrives.
Figure4.Frontviewofservermodelswith3.5-inchharddiskdrives
13.5-inchhard-disk-drivearea
5Diagnosticpanel(variesbymodel)
2Rackhandle(left)6Slimopticaldrive(availableinsomemodels)
3Pull-outinformationcard
7Rackhandle(right)
4Frontpanel
