Componentsofservermodelswith2.5-inchhot-swapharddiskdrives
Figure18.Componentsofservermodelswith2.5-inchhot-swapharddiskdrives
1Coolingshroud13Slimopticaldrive(availableinsomemodels)
2Powersupplycoolingshroud
14Diagnosticmodule(variesbymodel)
3Risercardassembly2
15Rackhandle(left)
4Oneortwohot-swapredundantpowersupplies
16Frontpanelboard
5PCIExpresscard(s)(availableinsomemodels)17Systemfans
6CPU2DIMMs(varybymodel)18CPU1DIMMs(varybymodel)
7Backplane(s)for2.5-inchharddiskdrives19Heatsink(s)withmicroprocessor(s)underneath
8Rackhandle(right)20Systemboard
92.5-inchhard-disk-drivearea(rightcage)21Systemboardbattery
102.5-inchhard-disk-drivearea(middlecage)22PCIExpresscard(s)(availableinsomemodels)
11Pull-outinformationcard
23Risercardassembly1
12VGADB-15connector
CRUsarepartsthatcanbeupgradedorreplacedbythecustomer.IfaCRUisdeterminedtobedefective
duringthewarrantyperiod,areplacementCRUwillbeprovidedtothecustomer.Customersareresponsible
forinstallingtheself-serviceCRUsforthisproduct.Customersalsocaninstalloptional-serviceCRUs,which
mightrequiresometechnicalskillsortools,orrequestthatatechnicianinstalltheoptional-serviceCRU
underthetermsoftheapplicablewarrantyservicetypeforyourcountryorregion.
Chapter3.Productoverview33
