Backplaneforuptoeight2.5-inchdrives(withanAnyRAID-adapterslot)
Thefollowingillustrationsshowtheconnectorsonthebackplaneforuptoeight2.5-inchdrivers(with
anAnyRAID-adapterslotontheback).
0 1 2 3 4 5 6 7
Figure29.Frontview
8 9
10
11
Figure30.Rearview
0–7Slot0–slot7
Usedtoconnect2.5-inchSATA/SASHDDorSSDdrives.
810-pinpowerconnector0
Usedtoconnecttothe10-pinbackplanepowerconnectoronthesystemboardoronthepowerdistribution
boardtoprovidepowertothebackplane.
9AnyRAIDadapterslot0
UsedtoconnectanAnyRAIDadapter.
104-pinpowerconnector
Usedtoconnecttoaninternaltapedriveiftheserverhasoneinstalled.
112-pinpowerconnector
Usedtoconnecttoanopticaldriveiftheserverhasoneinstalled.
Chapter3.Productoverview45
