Backplaneforuptosix2.5-inchdrives
Thefollowingillustrationsshowtheslotsandconnectorsonthebackplaneforuptosix2.5-inchdrives.
0 1 2 3 4 5
Figure33.Frontview
6 7
Figure34.Rearview
0–1Slot0–slot1
Usedtoconnect2.5-inchhot-swapSATA/SASHDDorSSDdrives.
2–5Slot2–slot5
Usedtoconnect2.5-incheasy-swapPCIeSSDdrivesorhot-swapSATA/SASHDD/SSDdrives.
6Interposercardslot1
7Interposercardslot0
Usedtoconnectaninterposercard.
Chapter3.Productoverview47
