EDBMB935X EN 8.0
0Fig. 0Tab. 0
Scope of supply
Pos. Description
0 9350 braking unit
Accessory kit with shield sheets and fixing material
Operating Instructions
Elements of the braking unit
Pos. Description
1 Terminals
+UG, −UG DC−bus voltage
T1, T2 Temperature switches (only 9351 brake module)
RB1, RB2 Brake resistor (only 9352 brake chopper)
2 LED
Green Voltage is applied to terminals +UG, −UG
Yello
w
Braking unit is in braking operation
3 Switches
S1, S2 Setting the switching thresholds of the braking unit
S3 Setting of the configuration as master or slave for parallel operation
4 Synchronisation
interface
E1, E2 Inputs
A1, A2 Outputs
