C0421/3 ð 5: The monitoring signal “Motor voltage” is the signal source for
CAN-OUT1/word1.
l C0421/8 ð 61: The process data input wordCAN-IN2/word2 is the signal
source for CAN-OUT2/word 2.
)
))
) Note!
l The process data output words CAN-OUT1.W1/FIF-OUT.W1,
CAN-OUT2.W1 and FIF-OUT.W2 can also be assigned to
C0417 and C0418 with 16-bit status information each:
– With digital configuration under C0417 or C0418 no
simultaneous analog assignment with C0421 (C0421/x =
255)!
– With analog configuration under C0421 no simultaneous
digital assignment with C0417 and C0418 (C0417/x = 255,
C0418/x = 255)!
– Otherwise the output signal would be incorrect.
l The process data input words CAN-IN1.W1/FIF-IN.W1,
CAN-IN1.W2/FIF-IN.W2, CAN-IN2.W1 and CAN-IN2.W2 can be
defined as analog word or digital word (16 bit). If you link them
with analog process data output words (C0421/x = 50, 51 or
60, 61), they must be defined as analog input words. Otherwise
the output signal would be incorrect.
Examples
