Free connection of digital signals
Free configuration of digital input signals
10
Function library
10.13
10.13.1
L
10.13-3
EDS82EV903-1.0-11/2002
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0410
v
(cont.)
^
10.13-1
25
(A)
PCTRL1-FOLL1-0 255 Not assigned (FIXED-FREE) Compensator at reset ramp C0193 to ”0”
26
(A)
Reserved 255 Not assigned (FIXED-FREE)
27
(A)
NSET1-TI1/3 255 Not assigned (FIXED-FREE) Activate acceleration times
28
(A)
NSET1-TI2/3 255 Not assigned (FIXED-FREE) C0410/27 C0410/28
LOW LOW
HIGH LOW
LOW HIGH
HIGH HIGH
active
C0012; C0013
T
ir
1; T
if
1
T
ir
2; T
if
2
T
ir
3; T
if
3
29
(A)
PCTRL1-FA DING 255 Not assigned (FIXED-FREE) Process controller output on (LOW)/ off
(HIGH)
30
(A)
PCTRL1-INV-ON 255 Not assigned (FIXED-FREE) Process controller output inversion
31
(A)
PCTRL1-NADD-OFF 255 Not assigned (FIXED-FREE) Switch off additional setpoint
32
(A)
PCTRL1-RFG2-0 255 Not assigned (FIXED-FREE) Decelerate process controller ramp function
generator input to ”0” along ramp C0226
33
(A)
NSET1-JOG4/5/6/7 255 Not assigned (FIXED-FREE)
