Free connection of digital signals
Free configuration of digital input signals
10
Function library
10.13
10.13.1
L
10.13-4
EDS82EV903-1.0-11/2002
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0410 Dig ital signal sou rces for C0410 ^
v
(
t
)
0 Not assigned (FIXED-FREE)
10.13-1
(cont.)
1 Digital input X3/E1 (DIGIN1)
2 Digital input X3/E2 (DIGIN2)
3 Digital input X3/E3 (DIGIN3)
4 Digital input X3/E4 (DIGIN4)
5(A) Digital input X3/E5 (DIGIN5)
6(A) Digital input X3/E6 (DIGIN6)
7 PTC input (X2.2/T1, X2.2/T2) T1/T2 can only be connected to
potential-free switches!
T1/T2 is active (”HIGH”) when the swit ch is
closed
AIF control word (AIF-CTRL)
10 Bit 0
... ...
25 Bit 15
CAN-IN1.W1 or FIF-IN.W1
30 Bit 0
... ...
45 Bit 15
CAN-IN1.W2 or FIF-IN.W2
50 Bit 0
... ...
65 Bit 15
CAN-IN2.W1
70 Bit 0
... ...
85 Bit 15
CAN-IN2.W2
90 Bit 0
... ...
105 Bit 15
Status application I/O
Only active when using application I/O
140 Torque threshold 1 reached (MSET1=MOUT)
y
g
p
p
141 Torque threshold 2 reached (MSET2=MOUT)
142 Process controller output limit reached
(PCTRL1-LIM)
143...172 Reserved
200 Control words are assigned bit by bit from the
fieldbus function module to FIF (e.g. INTERBUS or
PROFIBUS-DP)
See C0005
Digital output signals
201 as C0415, selection 1
... ...
231 as C0415, selection 31
255 Not assigned (FIXED-FREE)
