Display of operating data, diagnostics
Display of operating data
10
Function library
10.16
10.16.1
L
10.16-2
EDS82EV903-1.0-11/2002
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0051* Output frequency
with slip
compensation
(MCTRL1-NOUT
+SLIP) or
act. process
controller value
(PCTRL1-ACT)
-650.00 {0.02 Hz} 650.00 The value set will be lost when
switching the mains!
Operation without process controller (C0238
=2):
• Display only: Output frequency with slip
compensation (MCTRL1-NOUT+SLIP)
Operation with process controller (C0238 =
0, 1):
• Selectio n, if C0412/5 = FIXED-FREE (not
assigned)
• Displa y if C0412/5 is linked with a signal
source
^ 10.10-6
C0052* Motor voltage
(MCTRL1-VOLT)
0 {V} 1000 Only display
C0053* DC-bus voltage
(MCTRL1-DCVOLT)
0 {V} 1000 Only display
C0054* Apparent motor
current
(MCTRL1-IMOT)
0.0 {A} 2000.0 Only display
C0056* Controller load
(MCTRL1-MOUT)
-255 {%} 255 Only display
C0061* Heatsink
temperature
0 {°C} 255 Only display
• If the heatsink temperature is > ϑ
max
-
5°C:
– The warning
OH will be sent.
– The chopper frequency will be
reduced to 4 kHz, if C0144 = 1
• If the heatsink temperature is > ϑ
max
:
– Controller sets TRIP
OH
C0138* Process controller
setpoint 1
(PCTRL1-SET1)
0.00 -650.00 {0.02 Hz} 650.00 The value set will b e lost wh en
switching the mains!
• Selection if C0412/4 = FIXED-FREE
• Display if C0412/4 ≠ FIXED-FREE
^ 10.10-5
C0189*
(A)
Output signal
compensator
(PCTRL1-FOLL1-OU
T)
-650.00 {0.02 Hz} 650.00 Only display
Compensator = PCTRL1-FOLL1
C0320
(A)
Actual process
controller value
(PCTRL1-ACT)
-650.00 {0.02 Hz} 650.00 Only display
C0321
(A)
Process controller
setpoint
(PCTRL1-SET)
-650.00 {0.02 Hz} 650.00 Only display
C0322
(A)
Process controller
output without
precontrol
(PCTRL1-OUT)
-650.00 {0.02 Hz} 650.00 Only display
C0323
(A)
Ramp function
generator input
(NSET1-RFG1-IN)
-650.00 {0.02 Hz} 650.00 Only display
C0324
(A)
Ramp function
generator output
(NSET1-NOUT)
-650.00 {0.02 Hz} 650.00 Only display
C0325
(A)
PID controller
output
(PCTRL1-PID-OUT)
-650.00 {0.02 Hz} 650.00 Only display
C0326
(A)
Process controller
output
(PCTRL1-NOUT)
-650.00 {0.02 Hz} 650.00 Only display
