Code table
10
Function library
10.20
L
10.20-7
EDS82EV903-1.0-11/2002
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0008
v
Fixed configuration
of relay output K1
(relay)
1
Change under C0008 will b e copied to
C0415/1. Free configuration under
C0415/1 sets C 0008 = 255!
^ 10.13-6
(
y
)
0 Ready for operation (DCTRL1-RDY)
1 TRIP fault message (DCTRL1-TRIP)
2 Motor is running (DCTRL1-RUN)
3 Motor is running / CW rotation (DCTRL1-RUN-CW)
4 Motor is running / CCW rotation
(DCTRL1-RUN-CCW)
5 Output frequency = 0 (DCTRL1-NOUT=0)
6 Frequency setpoint reached
(DCTRL1-RFG1=NOUT)
7 Value below frequenc y threshold Q
min
(f < C0017)
(PCTRL1-QMIN)
LOW active
8 I
max
limit reached (MCTRL1-IMAX)
C0014 = 5: Torque setpoint reached
9 Overtemperature (J
max
-5 °C)
(DCTRL1-OH-WARN)
10 Value below TRIP or Q
min
or pulse inhibit (IMP)
(DCTRL1-TRIP-QMIN-IMP)
11 PTC warning (DCTRL1-PTC-WARN)
12 Apparent motor current < current threshold
(DCTRL1-IMOT<ILIM)
Belt monitoring
Apparent motor current = C0054
13 Apparent motor current < current threshold and
output frequenc y > frequency threshold Q
min
(DCTRL1-(IMOT<ILIM)-QMIN)
p
p
Current t hreshold = C0156
Frequency threshold Q
min
= C0017
14 Apparent motor current < current threshold and
RFG 1: Input = output
(DCTRL1-(IMOT<ILIM)-RFG1=0)
15 Warning motor phase failure
(DCTRL1-LP1-WARN)
16 Minimum output frequency reached (f ≤ C0010)
(PCTRL1-NMIN)
LOW active
255 Free configuration under C0415/1 Only display
Do not change C0008 since settings under
C0415/1 can be lost
C0009*
v
Controller address 1 1 {1} 99 Only for communication modules on the AIF
interface:
• LECOM-A (RS232) E82ZBL
• LECOM-A/B/LI 2102
• PROFIBUS-DP 213x,
• System bus (CAN) 217x
During operation with th e E82ZAFCC
system bus function module the node
address must be set under C0350.
C0010
uSEr
Minimum output
frequency
0.00 0.00
à 14.5 Hz
{0.02 Hz} 650.00
• C0010 is not ef f e ctive with bipolar
setpoint selection (-10 V ... + 10 V)
• C0010 only defines the analog input 1
à
S
p
e
e
d
s
e
t
t
i
n
g
r
a
n
g
e
1
:
6
f
o
r
L
e
n
z
e
^ 10.6-1
C0011
uSEr
Maximum output
frequency
50.00 7.50
à 87 Hz
{0.02 Hz} 650.00
à Speed setting range 1 : 6 for Lenze
geared motors: Setting absolutely
required f or operation with Lenze
geared motors.
C0012
uSEr
Acceleration time
main setpoint
5.00 0.00 {0.02 s} 1300.00 Reference: frequency change 0 Hz ...
C0011
• Additional setpoint ð C0220
• Acceleration times can be activated via
digital signals
ð C0101
^ 10.7-1
