Lenze E82EV113K4C

Type-specific accessories
Operation with rated power (mains voltage 3/PE AC 400 V)
17
Accessories (o ver view)
17.3
17.3.5
L
17.3-5
EDS82EV903-1.0-11/2002
17.3.5 Operation with rated power (mains voltage 3/PE AC 400 V)
Mains voltag e 3//PE AC 400 V
8200 vector
g
E82EV551K4C
4)
E82EV751K4C
4)
E82EV152K4C
4)
E82EV222K4C
4)
Accessories Order no.
E.l.c.b. EFA3B06A EFA3B06A EFA3B10A EFA3B10A
Fuse EFS M-0060AWE EFSM-0060AWE EFSM-0100AWE EFSM-0100AWE
Fuse holder EFH10001
Mains choke EZN3A1500H003 E82ZL22234B
RFI filter S D
1)
E82ZZ75134B200 E82ZZ22234B200
RFI filter LD
1)
E82ZZ75134B210 E82ZZ22234B210
Motor filter E82ZM75134B E82ZM22234B020
Brake resistor ERBM470R100W ERBM370R150W ERBM240R200W
Swivel support E82ZJ001
DIN rail mounting E82ZJ002
EMC shield connection E82ZWEM2
PTC kit E82ZPE2
DC fuse without signalling device EFSGR0060AYHN EFSGR0100AYHN EFSGR0120AYHN
DC fuse with signalling device EFS GR0060AYH K EFSGR0100AYHK EFSGR0120AYHK
Plug connector (function module contact) E82ZJ011
1)
Only in combination with 8200 vector, types E82EVxxxKxC200
2)
For operation with mains choke
3)
Always use a mains choke
4)
The fo llowing a pplies t o the 8200 vector with EMC filte r:
In the mains voltage range of 484 V (-0%)
¼550 V (+0%) operation is only permissible when using a brake
resistor
Mains voltag e 3//PE AC 400 V
8200 vector
g
E82EV302K4C E82EV402K4C E82EV552K4C E82EV752K4C E82EV113K4C
Accessories Order no.
E.l.c.b. EFA3B16A
EFA3B10A
2)
EFA3B16A EFA3B25A
EFA3B20A
2)
EFA3B32A
EFA3B20A
2)
EFA3B32A
Fuse EFSM-0160AWE
EFSM-0100AWE
2)
EFSM-0160AWE EFSM-0250AXH
EFSM-0200AWE
2)
EFSM-0320AWH
EFSM-0200AWE
2)
EFSM-0320AWH
Fuse holder EFH10001 EFH10002
EFH10001
2)
EFH10002
EFH10001
2)
EFH10002
Mains choke EZN3A 0500H007 EZN3A0300H013 ELN3-0120H017 ELN3-0150H024
3)
RFI filter S D
1)
E82ZZ55234B200 E82ZZ11334B200
RFI filter LD
1)
E82ZZ55234B210 E82ZZ11334B210
Motor filter E82ZM40234B E82ZM75234B E82ZM11334B
Brake resistor ERBD180R300W ERBD100R600W ERBD082R600W ERBD068R800W ERBD047R01K2
Swivel support E82ZJ005 E82ZJ006
EMC shield connection E82ZWEM3
PTC kit E82ZPE3
DC fuse without signalling device EFS GR0200AYH N EFSGR0250AYHN EFSGR0320AYHN EFSGR0400AYHN
DC fuse with signalling device EFSGR0200AYHK EFS G R0250AYHK EFSGR0320AYHK EFSGR0400AYHK
Plug connector (function module contact) E82ZJ011
1)
Only in combination with 8200 vector, types E82EVxxxKxC200
2)
For operation with mains choke
3)
Always use a mains choke
