Type-specific accessories
Operation with rated power (mains voltage 3/PE AC 400 V)
17
Accessories (o ver view)
17.3
17.3.5
L
17.3-6
EDS82EV903-1.0-11/2002
Mains voltag e 3//PE AC 400 V 8200 vector
g
E82EV153K4B201 E82EV223K4B201
2)
E82EV303K4B201
2)
E82EV453K4B201
2)
Accessories Order no.
Built-on mains filter A
1)
EZN3A 0110H030 EZN3A0080H042 EZN3A0055H060 EZN3A0037H090
Built-on mains filter B
1)
EZN3B0110H030 EZN3B0080H042 EZN3B0055H060 EZN3B0037H090
Footprint RFI filter E82ZZ15334B230 – – –
Footprint mains filter E82ZN22334B230 E82ZN22334B230 E82ZN30334B230 E82ZN45334B230
Mains choke ELN3-088H035 ELN3-0075H045 ELN3-0055H055 ELN3-0038H085
Motor filter ELM3-004H055 ELM3-004H055 on request
Sinusoidal filter on request
Brake module EMB9351-E
Brake chopper EMB9352-E
Brake resistor ERBD033R02K0 ERBD022R03K0 ERBD018R03K0 ERBD022R03K0
Mains voltag e 3//PE AC 400 V 8200 vector
g
E82EV553K4B201
2)
E82EV753K4B201
2)
E82EV903K4B201
2)
Accessories Order no.
Built-on mains filter A
1)
EZN3A 0030H110 EZN3A 0022H150 EZN3A0017H200
Built-on mains filter B
1)
EZN3B0033H110 EZN3B0022H150 EZN3B0017H200
Footprint mains filter E82ZN55334B230 E82ZN75334B230 E82ZN90334B230
Mains choke
1)
ELN3-0027H105 ELN3-0022H130 ELN3-0017H170
Motor filter on request on request on request
Sinusoidal filter on request on request on request
Brake module EMB9351-E EMB9351-E EMB9351-E
Brake chopper EMB9352-E EMB9352-E EMB9352-E
Brake resistor ERBD018R03K0 ERBD022R03K0 ERBD018R03K0
1)
Only in combination with 8200 vector, types E82EVxxxKxB201
2)
Always use a mains choke or mains f ilter
