Lenze E82EV113K4C

Type-specific accessories
Operation with increased rated power (mains voltage 3/PE AC 400 V)
17
Accessories (o ver view)
17.3
17.3.6
L
17.3-7
EDS82EV903-1.0-11/2002
17.3.6 Operation with increased rated power (mains voltage 3/PE AC 400 V)
Mains voltag e 3//PE AC 400 V
8200 vector
g
E82EV551K4C E82EV751K4C E82EV222K4C E82EV302K4C E82EV402K4C
Accessories Order no.
E.l.c.b. EFA3B06A EFA3B06A EFA3B10A EFA3B16A
EFA3B10A
2)
EFA3B16A
Fuse EFSM-0060AWE EFSM-0060AWE EFSM-0100AWE EFSM-0160AWE
EFSM-0100AWE
2)
EFSM-0160AWE
Fuse holder EFH10001
Mains choke EZN3A 1500H003 EZN3A1500H003
3)
EZ82ZL 22234B
3)
EZN3A 0300H013 EZN3A0300H013
3)
RFI filter S D
1)
E82ZZ75134B200 E82ZZ22234B200 E82ZZ55234B200
RFI filter LD
1)
E82ZZ75134B210 E82ZZ22234B210 E82ZZ55234B210
Motor filter E82ZM75134B E82ZM22234B020 E82ZM40234B
Brake resistor ERBM470R100W ERBM240R200W ERBD180R300W ERBD100R600W
Swivel support E82ZJ001 E82ZJ005
DIN rail mounting E82ZJ002 –
EMC shield connection E82ZWEM2 E82ZWEM3
PTC kit E82ZPE2 E82ZPE3
DC fuse without signalling device EFSGR060AYHN EFSGR0120AYHN EFS GR0200AYH N EFSGR0250AYHN
DC fuse with signalling device EFSGR060AYHK EFSGR0120AYHK EFSG R0200AYHK EFSGR0250AYHK
Plug connector (function module contact) E82ZJ011
1) Only in combination with 8200 vector, types E82EVxxxKxC200
2) For operation with mains choke
3) Always use a mains choke
Mains voltag e 3//PE AC 400 V
8200 vector
g
E82EV153K4B201
2)
E82EV223K4B201
2)
E82EV303K4B201
2)
E82EV453K4B201
2)
Accessories Order no.
Built-on mains filter A
1)
EZN3A 0080H042 EZN3A0060H054 EZN3A0055H060 EZN3A0030H110
Built-on mains filter B
1)
EZN3B0080H042 EZN3B0060H054 EZN3B0055H060 EZN3B0030H110
Footprint mains filter E82ZN22334B230 E82ZN30334B230 – –
Mains choke
1)
ELN3-0075H045 ELN3-0055H055 ELN3-0055H055 ELN3-0027H105
Motor filter ELM3-004H055 on request
Sinusoidal filter on request
Brake module EMB9351-E
Brake chopper EMB9352-E
Brake resistor ERBD033R02K0 ERBD022R03K0 ERBD018R03K0 ERBD022R03K0
Mains voltag e 3//PE AC 400 V 8200 vector
g
E82EV153K4B201
2)
E82EV223K4B201
2)
E82EV303K4B201
2)
Accessories Order no.
Built-on mains filter A
1)
– EZN3A0022H150 EZN3A0017H200
Built-on mains filter B
1)
– EZN3B0022H150 EZN3B0017H200
Footprint mains filter – E82ZN90334B230 –
Mains choke
1)
ELN3-0022H130 ELN3-0017H170 ELN3-0014H200
Motor filter on request
Sinusoidal filter on request
Brake module EMB9351-E
Brake chopper EMB9352-E EMB9352-E (3 x) EMB9352-E (3 x)
Brake resistor ERBD018R03K0 (2 x) ERBD022R03K0 ERBD018R03K 0
1) Only in combination with 8200 vector, types E82EVxxxKxB201
2) Always use a mains choke or mains filter
