Communication manual 8400 motec PROFIBUS
Product description
Features and variants
3.2 Features and variants
The communication unit PROFIBUS is available in the following versions:
The PROFIBUS communication unit is ...
– mounted on the wiring unit (E84DGVNxx);
– supplied internally via the drive unit (E84DGDVxxxxxxxx) or externally via a
separate voltage source.
The I/O connections can be brought into the device via M12 connectors or cable glands.
Devices without integrated safety system (safety option) have no analog input and no
relay output.
The integrated safety system of the E84DGFCPxJx communication units can be used on
machines for the protection of persons.
Support of the parameter data channel DRIVECOM (DP-V0), PROFIDrive (DP-V1) in
preparation
Exchange of up to 8 process data words per direction
Bus coupling via remote bus according to the RS485 standard
Automatic detection of the baud rate (9.6 kbps to 12 Mbps)
Setting of the station address is possible via DIP switch or code.
Communication with the Lenze »Engineer« (access to all Lenze parameters) is executed
via the diagnostic interface of the drive unit.
Product series Type designation Features
Enclosure
IP 65
PROFIBUS
M12
I/O: Terminal
I/O: M12
Safety
Inverter Drives 8400 motec
Communication unit PROFIBUS
E84DGFCPANP zzz
E84DGFCP9NP zz z
E84DGFCPAJP zzz z
E84DGFCP9JP zz zz
Hardware manual "Inverter Drives 8400 motec"
Here you will find detailed information on the integrated safety system (safety
option).
Software manual / »Engineer« online help "Inverter Drives 8400 motec"
Here you will find detailed information on how to configure the safety system
(safety option).
