Communication manual 8400 motec PROFIBUS
Parameter data transfer
DRIVECOM parameter data channel (DP-V0)
46 L EDS84DMOTPBUS EN 3.0 - 11/2011
9.2.3 Byte 2: Subindex
Additional addressing via the subindex is required for those codes of the Inverter Drives
8400 motec that contain subcodes (see code table).
9.2.4 Bytes 3 + 4: Index
The parameter (Lenze code) is selected via these two bytes according to the formula:
 Index = 24575 - Lenze code number
(See also "Addressing of Lenze parameters
" ( 41))
Example:
The parameter C00105 (quick stop (QSP) deceleration time) is to be addressed:
 Index = 24575 - 105 = 24470 = 0x5F96
 The entries in bytes 3 + 4 for this example would be:
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
Service Subindex Index
High byte
Index
Low byte
Data 4 /
Error 4
Data 3 /
Error 3
Data 2 /
Error 2
Data 1 /
Error 1
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
Service Subindex Index
High byte
Index
Low byte
Data 4 /
Error 4
Data 3 /
Error 3
Data 2 /
Error 2
Data 1 /
Error 1
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
Service Subindex 0x5F 0x96 Data 4 /
Error 4
Data 3 /
Error 3
Data 2 /
Error 2
Data 1 /
Error 1
