Lenze E84DGFCp Series User Manual

EDS84DMOTPBUS EN 3.0 - 11/2011 L 83
Communication manual 8400 motec PROFIBUS
Parameter reference
Parameters relevant for PROFIBUS communication
C13853
C13860
C13861
Parameter | Name:
C13853 | All words from standard device
Data type: UNSIGNED_16
Index: 10722
d
= 29E2
h
Display of the process data words 1 ... 8 transferred from the drive unit to the communication unit.
In the subcodes 1 ... 8, all process data words of the drive unit are displayed.
Display area (min. value | unit | max. value)
0 65535
Subcodes Info
C13853/1 Word 1 from drive unit
... ...
C13853/8 Word 8 from drive unit
; Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13860 | Settings
Data type: UNSIGNED_8
Index: 10715
d
= 29DB
h
Display of the current configuration data.
Display area (min. value | unit | max. value)
0 255
Subcodes Info
C13860/1 Reserved
C13860/2 Number of process data words
•1 ... 8 words
C13860/3 DRIVECOM parameter data channel
• 0: Not active
•1: Active
C13860/4 Reserved
; Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13861 | Bus status
Data type: UNSIGNED_16
Index: 10714
d
= 29DA
h
Bit-coded display of the current bus state.
Querying the current bus status
( 74)
Display area (min. value | unit | max. value)
0 65535
; Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
