Communication manual 8400 motec PROFIBUS
DIP switch positions for setting the station address
94 L EDS84DMOTPBUS EN 3.0 - 11/2011
38 OFF ON OFF OFF ON ON OFF
39 OFF ON OFF OFF ON ON ON
40 OFF ON OFF ON OFF OFF OFF
41 OFF ON OFF ON OFF OFF ON
42 OFF ON OFF ON OFF ON OFF
43 OFF ON OFF ON OFF ON ON
44 OFF ON OFF ON ON OFF OFF
45 OFF ON OFF ON ON OFF ON
46 OFF ON OFF ON ON ON OFF
47 OFF ON OFF ON ON ON ON
48 OFF ON ON OFF OFF OFF OFF
49 OFF ON ON OFF OFF OFF ON
50 OFF ON ON OFF OFF ON OFF
51 OFF ON ON OFF OFF ON ON
52 OFF ON ON OFF ON OFF OFF
53 OFF ON ON OFF ON OFF ON
54 OFF ON ON OFF ON ON OFF
55 OFF ON ON OFF ON ON ON
56 OFF ON ON ON OFF OFF OFF
57 OFF ON ON ON OFF OFF ON
58 OFF ON ON ON OFF ON OFF
59 OFF ON ON ON OFF ON ON
60 OFF ON ON ON ON OFF OFF
61 OFF ON ON ON ON OFF ON
62 OFF ON ON ON ON ON OFF
63 OFF ON ON ON ON ON ON
64 ON OFF OFF OFF OFF OFF OFF
65 ON OFF OFF OFF OFF OFF ON
66 ON OFF OFF OFF OFF ON OFF
67 ON OFF OFF OFF OFF ON ON
68 ON OFF OFF OFF ON OFF OFF
69 ON OFF OFF OFF ON OFF ON
70 ON OFF OFF OFF ON ON OFF
71 ON OFF OFF OFF ON ON ON
72 ON OFF OFF ON OFF OFF OFF
73 ON OFF OFF ON OFF OFF ON
74 ON OFF OFF ON OFF ON OFF
75 ON OFF OFF ON OFF ON ON
76 ON OFF OFF ON ON OFF OFF
77 ON OFF OFF ON ON OFF ON
78 ON OFF OFF ON ON ON OFF
79 ON OFF OFF ON ON ON ON
80 ON OFF ON OFF OFF OFF OFF
Station address DIP switch
64 32 16 8 4 2 1
