Lenze ECSEE040 - Automation Interface (AIF)

Electrical installation
Automation interface (AIF)
5

52
EDBCSXE040 EN 6.0
5.5 Automation interface (AIF)
The keypad XT or a communication module can be attached to or removed from the
automation interface (X1). This is also possible during operation.
ƒ The keypad XT serves to enter and visualise parameters and codes.
ƒ The communication modules serve to network the power supply modules and axis
modules of the ECS servo system with the host system (PLC or PC).
The following combinations are possible:
Operating/communication module Type/order number
Can be used together with
ECSxE ECSxS/P/M/A
Keypad XT EMZ9371BC ü ü
Diagnosis terminal (keypad XT with hand−held) E82ZBBXC ü ü
LECOM−A (RS232) EMF2102IB−V004 ü ü
LECOM−B (RS485) EMF2102IB−V002 ü ü
LECOM−A/B (RS232/485) EMF2102IB−V001 ü ü
LECOM−LI (optical fibre) EMF2102IB−V003 ü ü
LON EMF2141IB ˘ ü
INTERBUS EMF2113IB ˘ ü
PROFIBUS−DP EMF2133IB ˘ ü
CANopen/DeviceNet EMF2178IB, EMF2179IB ˘ ü
EtherCAT EMF2192IB ü ü
 Further information ....
on wiring and application of communication modules can be found in the
corresponding Mounting Instructions and Communication Manuals.
