Commissioning
Operation with external brake resistor
6
66
EDBCSXE040 EN 6.0
6.5 Operation with external brake resistor
When an external brake resistor is used, monitoring of the internal brake resistor (OC6)
must be deactivated with C0579 = 3.
ƒ C0579 can be found in the GDC parameter menu ( 71) under Short setup and
Monitoring.
Stop!
The device can be destroyed if the monitoring is deactivated while the internal
brake resistor is used.
Parameter
C0579
Designation
Response − monitoring of internal brake resistor (OC6)
Data type: INTEGER_32
Index: 23996
dec
= 5DBC
hex
Monitoring response of the internal brake resistor (fault message OC6)
116
Selection list (Lenze setting printed in bold) Information
0 TRIP
3 No response
