Lenze−Codestellen und CANopen−Objekte
Description of the general codes
8
l
59
EDSMF2181IB EN 3.0
C0200:
Software ID
Code
C0200
Name
Software manufacturer’s product code
Index: 0x5F37 (24375)
Subcode Lenze Values Access Data type
g
ro VS
¨ RSPþ PS transfer ¨ CANopen:
During initialisation of the module it is determined which device is connected as a user
based on the manufacturer’s product code.
Value displayed for the 2181 communication module:
"33S2181F_10000".
C1213:
Fieldbus connection
Code
C1213
Name
Fieldbus connection
Index: 0x5B42 (23362)
Subcode Lenze Values Access Data type
0 0, 1 rw FIX32
¨ RSPþ PS transfer ¨ CANopen:
In code C1213, the fieldbus connection has to be entered:
C1213 = 0: connection of modemCAN 2181 and the inverter via the CAN bus.
C1213 = 1: connection of modemCAN 2181 with the diagnostic interface of the
inverter9400.
) Note!
It is not possible to operate both connections of the communication module in
parallel.
