F
E
NOTICE
▶
Independent of the mounng order, the output sha must be aligned with the machine
sha.
How to mount the foot to the gearbox:
1.
Fasten foot to gearbox with 4 screws in "Posion F" and 2 screws in "Posion E
2.
Fasten gearbox with foot to machine housing with 4 screws
How to mount the foot to the machine housing:
1.
Fasten foot to machine housing with 4 screws
2.
Fasten foot to gearbox with 4 screws in "Posion F" and 2 screws in "Posion E
How to align the gearbox sha with the machine sha:
1.
Loosen xing screws "foot on gearbox" and "foot on machine housing" unl the foot can
be moved on both the gearbox and the machine housing
2.
Output sha aligned with machine sha
3.
Tighten the xing screws "foot on gearbox" and "foot on machine housing"
4.
Check alignment of gearbox sha to machine sha, improve alignment if necessary and
repeat steps 1 to 3
Tightening torques for mounng the foot to the gearbox
Product code Tightening torque
Nm
G50BS113 + G50BS122 10
G50BS140 + G50BS166 48
Mechanical installaon
Mounng
31
