Overview
Operang Instrucons i510-Cabinet
1 Overview
Hardware overview of the inverter
Shield connecon
PE connecon
Mains connecon/DC bus
Relay output
Network
Interface
Control terminals
Shielding of control connecons
IT screw
IT screw from 0.55 kW
Inverter status s LED
Motor connecon
Opon
Opon
Basic I/O
Diagnosc module
Brake resistor connecon
Memory module
Netword status sLED
Toggle switch
CANopen/Modbus
X100
X16
X3
X20
X105
X216
X9
