General informaon
Operang Instrucons i510-Cabinet
1 Generalinformaon
Please read this documentaon carefully before installing the inverter and observe the safety
instrucons!
This document only includes the most frequently asked quesons and presents them in a
simplied form for a beer overview. Detailed technical and funconal explanaons can be
found in the comprehensive product documentaon.
The complete documentaon, further informaon and tools regarding Lenze products can be
found on the Internet: hp://www.Lenze.com
1.1 Target group
Work on the product must only be carried out by qualied personnel. Specialist personnel
must be qualied in accordance with IEC 60364 or CENELEC HD 384. Qualied personnel are
persons who have the following knowledge and experience:
• They are familiar with the installaon, mounng, commissioning, and operaon of
electrical and electronic modules.
• They have the corresponding qualicaons for their work.
• They know and can apply all regulaons for the prevenon of accidents, direcves, and
laws applicable at the place of use.
1.2 Applicaonasdirected
The product is designed for the installaon into electrical systems or machinery.
The i500 product family is designed for the power range of 0.25 ... 15 kW. The inverter
i510 is suitable for conveyor and travelling drives, pumps, fans, winders, liing systems and
many other machine tasks. The inverter is not to be used as a household appliance, but for
commercial or professional purposes only.
The inverter is not a machine in terms of the Machinery Direcve.
1.3 Device-specicstandardsanddirecves
• The product meets the protecon requirements of the Low-Voltage Direcve 2014/35/EU.
• The harmonized standard EN 61800-5-1 is used for the inverters.
1.4 Relevantstandardsanddirecvesfortheoperator
Applicaonasdirected
• If the product is used in accordance with the technical data, the drive systems comply with
the EN 61800-3 categories.
• The inverter may only be used commercially or professionally as dened by EN 61000-3-2.
• The test voltage for insulaon resistance tests between a control potenal of 24 V and PE
must be measured in accordance with EN 61800-5-1.
• The cables must be installed in accordance with EN 60204-1 or US Naonal Electrical Code
NFPA 70 / Canadian Electrical Code C22.1.
Commissioning
• Commissioning or starng the operaon as directed of a machine with the product
is prohibited unl it has been ensured that the machine meets the regulaons of the
Machinery Direcve (2006/42/EC) and the standard EN 60204-1.
• Commissioning or starng the operaon as directed is only permissible if the EMC
Direcve 2014/30/EU is complied with.
