Mechanical installation
Mounting
Breather position, oil filling screw and drain plug
4
l
46
BA 12.0023−EN 6.0
Bevel gearbox GKR 05...06−2
A B
C D
E F
GT−GNG−GKR−2−001_A−F.iso/dms
A...F Mounting positions Breathing / oil filler plug
