Mounng posions
Gear
ed motors
In the following graphics, the terminal box in posion 2 is c
olour-coded. If the
mounng posion (A … F) changes, the terminal box posions (2 … 5) are
rotated accordingly.
To reduce the number of dierent versions, the gearboxes can also be ordered with combined
mounng posions:
•
g500-B45 in ABCDEF mounng posion
•
g500-B110 ... B450 in AEF mounng posion
A
B
C
D
F
E
Product in
formaon
