Lenze Smart Motor m300-E - Motor Connection

Motor c
onnecon
The QUICKON connecon enables fast and easy connecon of motors. The equipment is easy
to cable by means of a connecng cable with the QUICKON nut.
QUICKON nuts and QUICKON connectors with QUICKON nuts are available as
accessories.
Mains connecon X3
Pin assignment for QUICKON connector
Contac
t
Name Meaning
1 L1 Mains connecon Phase L1
1
2
3
PE
2 L2 Mains c
onnecon Phase L2
3 L3 Mains c
onnecon Phase L3
4 PE PE conductor
Pin assignment for M15 connector
Contac
t
Name Meaning
1 L1 Mains c
onnecon Phase L1
2
3
A
B
1
+
2 L2 Mains c
onnecon Phase L2
3 L3 Mains connecon Phase L3
PE PE PE conductor
A Not assigned
B
Note for the orientaon of a right-angle plug:
The posion of the contact "2" at the terminal box is in the direcon of the terminal box cover.
Terminal assignment in the terminal box
Contac
t
Name Meaning
1 L1 Mains c
onnecon Phase L1
2 L2 Mains connecon Phase L2
3 L3 Mains connecon Phase L3
PE PE PE conductor
Control c
onnecons with M12 connectors
Via the digital inputs of the two M12 control connecons, it is possible to switch between
dierent speeds and direcons of rotaon. Up to 5 dierent speed sengs (e. g. creep speed
and normal speed in both direcons, as well as stop) can thus be selected. In addion, the
operang state is indicated via a digital output.
NOTICE
In the "DI/DO-GND bridged" version, the masses of the control terminal X1 and X2 (GND-I and
GND-O) ar
e connected to each other. If only one speed is used, the connecon to X2 is
sucient.
Control terminal X1
Pin assignment for M12 connector A coded, pins
Contac
t
Name Meaning
1 n.c.
1
2
4
3
2 DI2 Digital input 2
3 GND-I Mass of digital input
4 DI1 Digital input 1
Product extensions
Mot
or connecon
