QUICKON connector
Nuts f
or QUICKON connecon
For fast and easy QUICKON connecon, the following nuts (counterparts) can be ed to the
connecng cable. No special tools are needed for installaon, only standard tools for stripping
the cable.
NOTICE
In the case of the capability for frequent c
onnecons (>10 mes) a QUICKON connector with
nut must be used.
QUICKON nut QUICKON connector with QUICKON nut
QUICKON connector, 4-pole
Type VPE Order code
Piece
QUICKON nut
Cable diameter: 6 … 10 mm 1 EWS0088
Cable diameter: 9 … 14 mm 1 EWS0089
QUICKON connector with QUICKON nut
Can be plugged in and disconnected safe from touch
Cable diameter: 6 … 10 mm 1 EWS0090
Cable diameter: 9 … 14 mm 1 EWS0091
UMCLN_SGG_100181
The following connector can be mounted to the c
onnecng cable for the M15 connecon.
M15 connector
Type VPE Order code
Piece
Connecon cr
oss-secon: 2.5 mm
2
Can be assembled in the eld
Plascs without shielding
Crimp sockets included in the scope of supply
5 EWS0109/M
Accessories
