LevelOne FCS-4042 - Waterproof Cable with Conduit Gland

Hardware Manual
21
How to Waterproof the Cable Using the Conduit Gland
1. Prepare the following items:
Conduit Gland
Gland Rubber Ring
1/2” Flexible Conduit
Waterproof Tape
NOTE: Not included
in the camera
package.
NOTE: Not included
in the camera
package.
2. Detach the conduit gland as shown below.
3. Insert the Ethernet cable through the flexible conduit. Then insert the clamping nut through
the flexible conduit.
Gland Body
Clamping Nut
Sealing Rubber
