Page 14 of 32
User Guide
Leviton MC 7500 Series Memory Lighting Controllers
Select Memory:
Use the “Mem” function button to select the type of memory to save. For each type of memory displayed, use the
Yes/No
function button to select it. Several types may be selected at a time.
Start Dump:
Press the Save button when the MIDI device is ready to accept the memory dump.
Reloading Memory:
Memory is automatically reloaded when the controller receives a proper MIDI system exclusive message.
Test saving and reloading with your MIDI device before programming the controller with an important
show.
Real Time Clock
Allows a stack to free run as if MIDI Time code (or SMPTE) was being input. With this enabled, the stack will continue
to run even if time code is received and then lost.
Real Time Clock MIDI Send More
Off Norm
MIDI Send
The MIDI send configuration can be set to Norm or Show. Norm indicates that standard MIDI commands, such as
note number or program changes will be transmitted as the console is operated. Show indicates that MIDI show
commands will be transmitted.
Real Time Clock MIDI Send More
Off Norm
Locks
The last menu sets the record and setup locks. The record lock prevents the RECORD and EDIT buttons from
operating. The Setup lock locks the configuration menu system. The key codes are 6157, (4257) and [2357].
Rec Lock Setup Lock
Off On
Once the Setup Lock is set, the key code is required to access the setup (configuration) parameters and
change the locks.
