Levitronix BPS-i600 User Manual

User Manual for BPS-i600
www.levitronix.com
PL-4089-00, Rev00, DCO# 21-271
5
System Name
Article #
Pump Head
Driver
Note
BPS-i600.1
100-91405
LPP-600.29
IPD-600.1-50-01
PFA pump head, Epoxy coated motor, 5 m PVC cable with open wires
BPS-i600.2
100-91406
LPP-600.29
IPD-600.2-50-01
PFA pump head, ETFE coated motor, 5 m FEP cable with open wires
Table 1: Standard system configurations
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
1
Pump Head
LPP-600.29
100-91403
Impeller / Housing
Housing Sealing
Inlet / Outlet Fittings
PFA / PFA
No sealing ring used. Pump housing is welded.
Tube 1”
Max. Flow
Max. Diff.-Pressure
Max. Viscosity
75 liters/min / 20 gallons/min
3.1 bar / 45 psi
20 cP
Max. Liquid Temp.
90 °C / 194 °F
2a
Integrated
Pump Driver
IPD-600.1-50-01
100-10179
Voltage, Power
48 VDC ± 10%, 600 W
Housing
Epoxy (corrosion resistant) coated alu., waterproof (IP65)
1
Cable
PVC jacket, open wires, cable length 5 m
Interfaces
PLC
with
- 1 analog input 4 – 20 mA
- 1 analog input 0 – 10 V OR 4 – 20 mA
- 1 analog output 0 – 10 V OR 4 – 20 mA
- 2 digital inputs 0 – 24 V (optocoupler)
- 2 digital outputs 0 – 24 V / 100 mA (open drain)
RS485 interface (for service and extended field operation).
Modbus protocol.
Standard Firmware
I1.48
2b
Integrated
Pump Driver
IPD-600.2-50-01
100-10180
Housing
ETFE (chemical resistant) coated alu., waterproof (IP65)
1
Cable
FEP jacket, open wires, cable length 5 m
Table 2: Specification of standard components
1: Designed and tested for IP67.
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
4
AC/DC Power
Supply
TSP 600-148-M
100-40013
Voltage / Power Output
Voltage Input
Certification
48 VDC / 600 W
85 – 265 VAC (automatic detection)
CB, UL, CSA, Semi F47
5
USB to RS485
Adaptor TR
Isolated
YN-485I-TR
100-30392
Structure/Design
USB connector (A) with termination resistor and cable with
connector pair (B and C) for external RS485 wire
connection. Magnetically isolated. Cable length is 2m.
Included is a USB space saver cable (D).
Purpose
Communication over fieldbus of driver with PC
6
Water Cooling
Module
WCM-i600.1
190-10465
Materials
Motor Mounting Screws
Cooling Flow
Pressure Drop
Max Static Pressure
Purpose
PTFE coated stainless steel for plate (A) and scews (B).
4 x M4x16, Inox A4 (PTFE coated)
Min. 0.5 l/min at ≤ 20 °C. In-/outlet are NPT 1/8”x6.9mm.
0.13 bar at 1 l/min (for water at 20°C)
4 bar
Driver cooling at higher liquid temp. (see Section 3.4)
Table 3: Specification of accessories

Levitronix BPS-i600 Specifications

General

Brand	Levitronix
Model	BPS-i600
Category	Water Pump
Language	English
