Levitronix PuraLev i30SU User Manual

User Manual for PuraLev
®
i30SU
www.levitronix.com
PL-4051-00, Rev03, DCO# 20-275
5
System Name
Article #
Pump Head Socket
Driver
Note
PLD-i30SU.1
PLD-i30SU.6
100-90955
100-91514
PHS-i30.1
PHS-i30.1
IPD-30.1-50-02
IPD-30.12-50-02
OEM - Driver, 5 m PVC cable with open wires, pump head socket
OEM - ATEX/IECEx - 5 m FEP cable with open wires, pump head socket.
PLD-i30SU.2
100-91025
PHS-i30.1
IPD-30.3-02 (MBP-i30.1 included)
EasyConnect - Driver with interface connectors, pump head socket.
PLD-i30SU.3
100-91026
PHS-i30.1
IPD-30.5-02 (MBP-i30.1 included)
Stand-Alone - Driver with integrated user panel, pump head socket.
Table 1: Standard driver system configurations
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
1a
1b
Single-Use (SU)
Pump Head
DCP-30.2 (Barb)
DCP-30.1 (Triclamp)
100-90968
100-90959
Material Impeller/Housing
Housing Sealing
In-/Outlet Fittings
Polypropylene (FDA, USP Class VI, BSE/TSE/Animal free)
Infrared welding

Max. Flow
Max. Diff.-Pressure
Max. Viscosity
Max. Liquid Temp.
7.7 liters/min / 2.0 gallons/min
1.0 bar / 14.5 psi
40 cP
60 °C / 140 °F
Wet Pump
Volume/Surface
7.7 ml / 55.9 cm
2
Sterilization Methods
Gamma radiation up to 40kGy
1c
1d
Irradiated SU Pump
Head
DCP-30.2-G25 (Barb)
DCP-30.1-G25 (Tricl.)
100-91071
100-91170
Applied Gamma Dosage
≥ 25 kGy
1e
Irradiated SU Pump
Head
with Sterile Fittings
DCP-30.2-SF1-G25
100-91234
Pump Type (A) / Tubing (C)
Sterile Fittings (B)
Fitting Compatibility
Applied Gamma Dosage
DCP-30.2 (Barb) / Silicone
AseptiQuik

S from CPC

with part # AQS17006
3
Various sizes and types including autoclavable versions available at CPC
®

2a
Integrated Pump Driver
(“OEM Model”)
IPD-30.1-50-02
100-10088
Voltage, Power
Housing / Cable
Interfaces
Standard Firmware
24 VDC ±10%, 35 W
Epoxy coated Alu., PP for bottom lid, IP65
1
/ PVC jacket, open wires, cable 5 m
PLC and RS485 with Modbus protocol
H2.48
2b
Integrated Pump Driver
(“EasyConnect” Model)
IPD-30.3-02
(MBP-i30.1 included)
100-10097
Housing
Interfaces
Standard Firmware
Epoxy coated Aluminum, PP for bottom lid, IP65
2x Fieldbus RS485 with Modbus protocol, PLC and power supply
H2.48
2
2c
Integrated Pump Driver
(“Stand-Alone” Model)
IPD-30.5-02
(MBP-i30.1 included)
100-10098
Housing
Interfaces
Standard Firmware
Epoxy coated Aluminum, PP for bottom lid, IP65
User panel with 3 user buttons, PLC and power supply
H2.25
2d
Integrated Pump Driver
ATEX /IECEx
(“OEM Model” only)
IPD-30.12-50-02
100-10203
Housing / Cable
Interfaces
ATEX / IECEx Marking
Standard Firmware
ETFE coated Alu., IP65
1
/ FEP jacket, open wires, cable length 5 m
PLC and RS485 with Modbus protocol
II 3G Ex ec h mc IIC T4 Gc / II 3D Ex h tc IIIC T90°C Dc
H2.48
3
Pump Head Socket
PHS-i30.1
100-90947
Mounting Type
Material
Assembly Screws
Bayonet type with locking pin
Anodized Aluminum
4 pcs M3 x 6 mm (Stainless Steel, INOX A4)
Table 2: Specification of standard components
Note 1: Designed and tested for IP67. Note 2: Special firmware for serial pumping as one unit (Figure 6) available on request. Note 3: CPC
®
and AseptiQuik
®
are registered marks of the Colder Product Company.
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
4
Mounting Base Plate
MBP-i30.1
190-10313
Material / Mounting
Screws
PP + 30% GF / 2 pieces, stainless steel FEP coated, M3 x 10 mm
5a
AC/DC Power Supply
TPC 055-124 (Traco)
100-40014
Voltage Output / Input
Basic Dimensions
Certification or Standards
24 VDC with 55 W / 85  264 VAC, 47-63 Hz
45 x 90 x 96.5 mm (mountable on DIN rail 35 mm)
UL, CSA, CB, Semi F47
5b
Desktop AC/DC Power
Supply
AC/DC Power Supply
VEC50US24 HR30
100-40015
Voltage Output / Input
Basic Dimensions
Safety Approvals
Note
24VDC, 50W / 90  264 VAC, 47-63 Hz
116 x 52 x 31 mm
IEC60950-1, EN60950-1, UL/cUL60950-1
Connector for direct connection to power supply of driver with 1.2m cable.
5c
AC Mains Cables
(for Desktop power supply 5b)
AMC-1.1 (2m)
AMC-1.2 (2.5m)
AMC-1.3 (2.5m)
AMC-1.4 (2.5m)
AMC-1.5 (2.5m)
190-10331
190-10332
190-10333
190-10334
190-10335
Approvals and Country
Approvals and Country
Approvals and Country
Approvals and Country
Approvals and Country
Cable Specifications
UL, cUL, US, Canada
CB, Germany, Denmark, Norway, Finland, Belg., Netherl., Sweden, Austria
PSE, Japan
Switzerland
CE, United Kingdom
Black color, ROHS
6
USB to RS485
Adaptor-TR Isolated
YN-485I-TR
100-30392
Structure/Design
USB connector (A) with termination resistor and cable (2m) with connector
pair (B and C) for external RS485 wire connection. Magnetically isolated.
Cable length is 2m. Included is a USB space saver cable (D).
Purpose
Communication over fieldbus of driver with PC
7
IPS Cable Power 3
Wires
ICP-1.1-50 (5 m)
190-10342
Cable Material / Wires
Connection In / Out
Main Purpose
PVC jacket / 3x 0.5 mm
2
(only 2 wires used, 1 is cut)
Open wires / Circular Hirose type to driver
Connection of -
8a
IPS Cable Signal 6
Wires
ICS-1.1-01 (0.1 m)
ICS-1.1-10 (1 m)
ICS-1.1-30 (3 m)
190-10343
190-10344
190-10345
Cable Material / Wires
Connection In / Out
Main Purpose
PVC jacket / 6x 0.08 mm
2
and shielding
Circular Hirose type / Circular Hirose type
-pump arrays)
8b
IPS Cable Signal 6
Wires
ICS-1.2-50 (5 m)
190-10346
Cable Material / Wires
Connection In / Out
Main Purpose
PVC jacket / 6x 0.08 mm
2
and shielding
Connector with screw type plug for open wire connection / Circular Hirose
type
-
9
IPS Cable Signal 12
Wires
ICS-2.1-50 (5 m)
190-10347
Cable Material / Wires
Connection In / Out
Main Purpose
PVC jacket / 12x 0.14 mm
2
and shielding
Connector with screw type plug for open wire connection / Circular Hirose type

10
Fieldbus Termination
Connector
FTC-1.1
190-10348
Materials
Main Purpose
PPS for connector housing and FPM for sealing.
Termination of fieldbus.
11
User Panel
LUI-B.1-01
100-30448
Interface / Housing Rating
Standard Firmware
RS485 / IP65
A3.00
12
ATEX Cable
Sealing System
ACS-A.1
(Roxtec)
100-90292
Sleeve (A) and Gasket (B)
Frame (C)
2x Cable Module (D)
Stainless Steel and EPDM
Roxylon (EPDM rubber)
Roxylon (EPDM rubber)
Note:
Lubricant (E) and measurement
plates (F) are included.
Table 3: Specification of accessories
Note 1: Designed and tested for IP67.
