14
5. Remove the new filters from their packaging and place them into the purifier with the pull tabs facing out. The white HEPA
filter should also be facing out with the gray pre-filter on top of it. [Figures 2.5 & 2.6]
Replacing the Air Filters (cont.)
Tabs should face the
opening.
Figure 2.5
Figure 2.8Figure 2.7
Figure 2.6
6. Replace the filter cover onto the housing, making sure the arrows on the housing and filter cover align. Turn the filter
cover clockwise to the lock position. [Figures 2.7 & 2.8]
7. Follow the instructions in the Resetting the Air Purifier on page 15 to complete the filter replacement process.
