Levolor Cellular Shades - INSIDE MOUNT (IM): MARKING BRACKET LOCATIONS; IMPORTANT: Bracket Alignment

INSIDE MOUNT (IM)
STEP 1: MARKING THE BRACKET LOCATIONS
•
Mark 2" in from each jamb for bracket location.
— If more than two installation brackets came with your order, space additional
bracket(s) evenly between the two end brackets.
— Mount into wood whenever possible.
• Center the brackets on your marks, then mark each of the screw holes.
— The minimum depth for installation brackets is 1¼".
— The minimum depth for a fully recessed mount is 2¼".
— Use the center screw hole when depth permits.
— Use both winged screwholes with shallow mounting depths.
IMPORTANT: Brackets must be level and aligned to each other.
Bracket
Bracket
2" Space Evenly
Jamb Jamb
Space Evenly
2"
ROOM SIDE
WINDOW SIDE
INSTALLATION
9Cellular Shades Motorized Control Lift
