Lewmar Pro Series Owners Installation, Operation & Basic Servicing Manual

9
P
ro-Series & Pro-Fish Windlass
GB
2
.4 Mo
d
e
l
1000 - 12
V
CIRCUIT
BREAKER/ISOLATOR
BATTERY
GUARDED
ROCKER
SWITCH
68000593
Fuse
3 A
CONTACTOR
0052531 - 12 V
68000240 - 70 A, 12 V
E
A
B
D
C
Shared
Down
Up
DOWN UP
DECK
FOOT SWITCH
SET
68000598 Black
68000597 White
HAND
HELD
CONTROL
68000599
+
+
R
Fi
g
. 2.4.1
A
+ B +
C
+ D + E =
12 V
U
p
to 15 m
(
50 ft
)
15.5 to 21 m
(
51 to 70 ft
)
21.5 to
3
0.5 m
(
71 to 100 ft
)
US
E
16 mm
2
(
4 AW
G)
25 mm
2
(
2 AW
G)
3
5 m
m
2
(
2 AW
G)

Lewmar Pro Series Specifications

General

Series	Pro Series
Gear Type	Spur Gear
Voltage	12V
Type	Electric Windlass
Handle Options	Manual Override (varies by model)
Mounting	Horizontal
