Lewmar V8 - V9 DECK UNIT DIMENSIONS

Lewmar V8/V9/V10/V12 Vertical Windlass ref 66300094 Iss.6 | 31
B
A
F
E
D
G
C
V9 DECK UNIT DIMENSIONS
A 395 mm E Ø241 mm
B 146 mm F 320 mm
C Ø150 mm G 465 mm
D 288 mm
P
W
D
D
(mm)
D
(inch)
P
(mm)
P
(inch)
W
(mm)
W
(inch)
14mm Studlink
14mm Studlink 14 0.550 56 2.205 50.4 1.984
16mm Studlink
16mm Studlink 16 0.630 64 2.520 57.6 2.268
16mm Shortlink
16mm Shortlink 16 0.630 48 1.890 56 2.205
16mm DIN 766 16 0.630 45 1.772 58 2.283
17.5mm Studlink
17.5mm Studlink 17.5 0.689 70 2.756 63 2.480
18mm Shortlink 18mm DIN 766 18 0.709 50 1.968 65 2.559
GD Version
GO Version
