18
5.2-2
5.2-1
5.3-2
5.3-3
5.3-4
5.3-1
5.2 Power up/down
To release anchor.
1. Release any anchor locks.
2. When safe, operate DOWN control.
To retrieve anchor.
• Retrieving the anchor is the reverse to the above.
• When safe, operate the UP control.
• Once anchor is retrieved, ensure it is adequately secured to an independent strong point.
• VX2/3 Gypsy No.66120009
• VX2/3 Gypsy/drum No.66120010
WARNING! Isolate the windlass
using circuit breaker/isolator.
5.3 Optional manual recovery kits (VX2/3 ONLY)
