Lewmar VX Series User Manual

VX2/3 PARTS LIST
KIT NO. KIT DESCRIPTION ITEMS INCLUDED QTY.
66000799 WINDLASS HANDLE 1(1)
66120001 VX2/3 GO TOP CAP REPLACEMENT 3(1)
66120002 VX2/3 BASE KIT 8(1), 14(1), 16(1), 18(1), 34(1), 35(4), 37(1), 42(1)
66120003 VX2/3 CHAIN COVER KIT 39(2), 40(1)
66120004 VX2/3 CONTROL ARM KIT 37(2), 38(1), 41(1), 42(1)
66120005 VX2/3 DRUM KIT 7(1), 30(1), 31(1)
66120006 VX2/3 GYPSY ONLY DRIVE KIT 3(1), 6(1), 15(1), 19(1), 20(1)
66120007 VX2/3 DRUM DRIVE KIT 2(1), 2(1), 2(1), 2(1), 2(1), 2(1), 2(1), 2(1)
66120008 VX2/3 MANUAL & KIT 1(1), 17(1), 21(4), 22(4), 23(4)
66120009 VX2/3 GO MANUAL RECOVERY RETAIL KIT 2(1)
66120010 VX2/3 GD MANUAL RECVOERY RETAIL KIT 32(1)
68120011 VX2/3 STRIPPER RING REPLACEMENT 13(1)
68120031 VX2 MOTOR G/BOX 700W 12v Sz50 IP ASSY 24(1)
68120032 VX2 MOTOR G/BOX 900W 24v Sz50 IP ASSY 25(1)
68120033 VX2+ MOTOR G/BOX 1000W 24v Sz50 IP ASSY 26(1)
68120034 VX2+ MOTOR G/BOX 1000W 12v Sz50 IP ASSY 27(1)
68120035 VX3 1500W 12v M/G-BOX 28(1)
68120036 vx3 MOTOR G/BOX 1500W 24v Sz50 IP ASSY 28(1)
68120040 GYPSY ASSY 6/7mm VX⅔ ST/ST 4(1), 5(2), 7(1), 9(1), 13(1)
68120041 GYPSY ASSY 8mm VX⅔ ST/ST 4(1), 5(2), 7(1), 9(1), 14(1)
68120042 GYPSY ASSY10mm DIN VX⅔ ST/ST 4(1), 5(2), 7(1), 9(1), 15(1)
68120043 GYPSY ASSY 10mm ISO VX⅔ ST/ST 4(1), 5(2), 7(1), 9(1), 16(1)
7.2 Parts list VX2/3
