31
The Sample code source you can download from
How to use this Demo Application
Source fi le: F75111_Dos_Src.rar
Binary fi le: F75111_Dos_Bin.rar
USERNAME & PASSWORD: sf
1.Boot Ms-Dos Operating System
2.execute "75WDT.EXE" binary fi le
3.Input 1 to Enable WDT timer or input 0 to Disable it.
4.input numbers of second for chip countdown and Reset Computer
http://tprd.info/lexwiki/index.php/IO_Device:F75111_under_DOS
3-6-1 IO Device: F75111 under DOS
F75111 Layout Picture
