5
1. Mobile Intel® Pentium N4200 1.1GHz / 2.5GHz, (Quad core), Mobile Intel® Celeron
N3350 1.1GHz / 2.4GHz (Dual core)
2. Apollo-Lake Integrated Graphics chipset, Mobile Intel® Pentium N4200 200MHz /
700MHz, Mobile Intel® Celeron N3350 200MHz / 650MHz
3. Support eDP 1.3 2 Lanes up to 1920 x 1200, DVI 1.2 1920 x 1080, HDMI 1.4b up to
3840 x 2160
4. DDR3L SODIMM slot x 1, up to 8GB
5. Support 2 x 10 / 100 / 1000 Mbps Intel LAN port.
6. Support 2 x RS232 auto switch to RS485 / RS422 by BIOS, 2 port internal
7. 4 x type A USB 3.0 and 2 x USB 2.0 internal (signal shared with Mini Cards)
8. ALC886 HD Audio Specifi cation 1.0 Two channel sound
9. Support extended 1 x full-size Mini PCIe card for PCIe x 1 and USB interface,
1 x full-size Mini PCIe card for mSATA and USB interface.
10. Support 1 SATA port
11. Hardware digital Input & Output, 4 x DI / 4 x DO, Hardware Watch Dog Timer,
0~255 sec programmable
12. Wide Range DC IN +9V~36V
13. PCB Dimension: 102 x 83 mm
1-1 Major Feature
