2-2
LXP-5 Owner's Manual
5. If you are using an instrument amplifier or preamplifier, start with the
LXP-5 MIX control straight up (50% effect). Gradually increase the
OUTPUT LEVEL control until the audio level heard from the amplifier is
approximately the same as when the LXP-5 is not connected.
The best setting for MIX depends on which program you are using, and
to a great extent, your personal taste; feel free to experiment.
MIX setting to use when
the LXP-5 is patched to
console effects send(s)
When using an instrument
amplifier or preamplifier,
the ideal MIX setting is
generally somewhere in
this range
n
INPUT
MIX
OUTPUT
n
INPUT
MIX
OUTPUT
4. If the LXP-5 inputs are connected to a console effects send, and the
outputs are connected to console channel strip inputs, set the console's
input level trim and fader to a setting typically used for line level inputs.
Then set the MIX control fully clockwise (100% effect) and gradually turn
up the LXP-5 OUTPUT LEVEL control until the right amount of audio is
present at the console.
