LXP-5 Owner's Manual
Patch Assignments available via ADJUST
ADJUST CONTROL
Knob Position SOURCE
MIN Patch Off
2 Adjust Knob
3 LFO Rate
4 Last Note
5 Low Note
6 High Note
7 Last Velocity
8 Chnl Aftertouch
9 MIDI Clock
10 Mod Wheel
11 Breath Control
12 Foot Control
13 Data Entry
14 Volume
15 Sustain Pedal
MAX Pitch Wheel
ADJUST THRESHOLD
Knob Position LEVEL
MIN 0
28
317
425
534
642
751
859
968
10 76
11 85
12 93
13 102
14 110
15 119
MAX 127
ADJUST CONTROL
Knob Position DESTINATION
MIN Delay 1 - Coarse
2 Feedback 1
3 Delay 2 - Coarse
4 Feedback 2
5 Delay 3 - Coarse
6 Pitch Interval
7 Decay Time
8 Treble Decay
9 Size*
10 High Cut Filter
11 Low Cut Filter
12 Reverb Balance
13 Input Level
14 Output Level
15 Output Balance
MAX LFO Rate
ADJUST SCALE
Knob Position FACTOR
MIN x(-2.0)
2 x(-1.0)
3 x(-0.8)
4 x(-0.6)
5 x(-0.4)
6 x(-0.3)
7 x(-0.2)
8 x(-0.1)
9 x 0.1
10 x 0.2
11 x 0.3
12 x 0.4
13 x 0.6
14 x 0.8
15 x 1.0
MAX x 2.0
Altering the Size parameter in real-time will cause the LXP-5 to mute briefly.
