Lexicon LXP-5 - REV 1 User Manual

4-3
MIDI Implementation Data
Active Setup Data
Byte Value Description
0 F0 (hex) System Exclusive
1 06 Lexicon ID
2 05 LXP-5 ID
3 0000 nnnn(bin) n = MIDI Channel 0-15
4 5E (hex) data byte count (94)
5 0vvv vvvv(bin) 7-bit data
.
.
.
98 0vvv vvvv
99 0sss ssss sumcheck of data bytes
100 F7 (hex) End of SysEx message
Stored (Single Program) Data
Byte Value Description
0 F0 (hex) System Exclusive
1 06 Lexicon ID
2 05 LXP-5 ID
3 0001 nnnn(bin) n = MIDI Channel 0-15
4 0ppp pppp p = register number 0 - 127
5 39 (hex) data byte count (57)
6 0vvv vvvv 7-bit data
.
.
.
62 0vvv vvvv
63 0sss ssss sumcheck of data bytes
64 F7 (hex) End of SysEx message
