Lexicon LXP-5 - REV 1 User Manual

4-5
MIDI Implementation Data
Data Byte # Data Param # Data Description
0 66 Program (Algorithm) ID
1 - 23 0 -22 Microcode Parameters
24 - 34 31 - 41 Name (11 characters)
35 42 Reserved
36 43 Knob Patch Destination
37 - 41 44 - 48 General Purpose Patch 1 Parameters
42 - 46 49 - 53 General Purpose Patch 2 Parameters
47 - 51 54 - 58 General Purpose Patch 3 Parameters
52 - 56 59 - 63 General Purpose Patch 4 Parameters
Active Setup Dump
The Active Setup data dump sends all the parameters for the current setup
as well as the global parameters. The format is:
Data Byte # Data Param # Data Description
0 66 Program (Algorithm) ID
1 - 23 0 - 22 Microcode Parameters
24 - 31 23 - 30 Knob Mechanism Parameters
32 - 42 31 - 41 Name (11 characters)
43 42 Reserved
44 43 Knob Patch Destination
45 - 49 44 - 48 General Purpose Patch 1 Parameters
50 - 54 49 - 53 General Purpose Patch 2 Parameters
55 - 59 54 - 58 General Purpose Patch 3 Parameters
60 - 64 59 - 63 General Purpose Patch 4 Parameters
65 64 Register Number
66 65 Preset Number
67 66 Program (Algorithm) ID
68 67 Footswitch mode
69 68 Memory Write Protect
70 69 Global Patch Enable
71 - 93 70 - 90 Global Patch Sources
