4-13
MIDI Implementation Data
Level Parameters
Note: The Reverb Balance and Output Balance parameters each act like a
conventional pan circuit with a 3 dB loss when set to a 50/50 mix. To insure
the best signal to noise ratio, the Output Level parameter includes 6 dB of
gain to offset these losses. As a result, however, the panning will be very
sharp when the Output Level is set at maximum (100%). A smoother pan can
be achieved by reducing the Output Level 3 dB (about 70%).
Parameter # Range: Increment Resolution
Pitch/Delay Delay/Reverb
Reverb Balance 18 100% effects/ 100% effects/ Follows sine/ 128 steps
0% reverb to 0% reverb to cosine curves
0% effects/ 0% effects/
100% reverb 100% reverb
Function: Adjusts the mix of reverb with delay effects.
Output Balance 19 100% left 100% left Follows sine/ 128 steps
to 100% right to 100% right cosine curves
Function: Provides a pan control for the wet output.
Output Level 20 0 - 100% 0 - 100% ≈ 0.79% 128 steps
Function: Adjusts the output level of the signal processor.
Input Level 21 0 - 100% 0 - 100% ≈ 0.79% 128 steps
Function: Adjusts the input level to the signal processor.
LFO Rate 22 0.066 - 10 Hz 0.066 - 10 Hz logarithmic 128 steps
approximation
Function: Adjusts the frequency of the low frequency oscillator.
