Lexington Forge CSDV30DNV - Alcove Installation Clearances

10 58D6056
ON
OFF
A
C
B
CLEARANCES / HEIGHT REQUIREMENTS
Figure 5 - Placing Stove in Alcove
Note: Maintain minimum side and back clearances when placing stove in alcove.
Height From
Hearth
A
Width
B
Depth
C
DV20 52" 30" 36"
DV30 64" 35" 36"
DV40 64" 35" 36"
Tested Minimum Alcove Dimensions
