34 58D6056
PILOT
OFF
REMOTE C
ONT
ROL
CLEANING AND MAINTENANCE
Clean the ceramic glass periodically. Condensation will sometimes form on the glass during a cold startup. This is normal
for all gas fireplaces and stoves. This condensation often attracts dust and lint to the surface of the glass. The initial paint
curing of the appliance can also leave a slight film on the glass. This is a temporary problem.
Your should clean the glass after the first two weeks of use. After that, you should clean the glass no more than two or
three times a season. Use a mild glass cleaner to clean the door. Do not use abrasive cleaners. They will damage the glass
surface.
PILOT AND BURNER FLAMES
Visually check pilot and burner flames periodically. See Figure 46 for typical burner flame. See Figures 45 and 46 for typi-
cal pilot flame.
Let glass cool before cleaning.
Do not clean glass when it is hot.
Damage could occur.
CAUTION
Make sure the gas valve knob is in the “OFF” position. Wait at least five (5) minutes before start -
ing maintenance.
VENTING SYSTEM
A qualified agency should examine the venting system annually.
CLEANING GLASS
Make sure clearances to combustibles
leave room for maintenance and
service.
WARNING
Carefully reassemble and reseal
stove properly after any cleaning or
servicing.
WARNING
FIREBOX CLEANING
1. Carefully remove log set, and embers from combustion
chamber.
2. Vacuum burner compartment thoroughly.
3. Vacuum any dust off logs.
4. Remove any lint from main burner and pilot.
5. Carefully replace log set and rock wool in their correct
positions. See page 28.
6. Replace door.
7. Relight pilot. See page 30.
8. Turn on main burner.
Figure 46 - Typical Burner Flame
Figure 47 - Typical Pilot
Flame (CSDV20 and CSDV30)
Thermopile
Thermocouple
Figure 48 - Typical Pilot
Flame (CSDV40)
