Action Yes No
Step 8
Check the green, yellow, and blue cables connecting the JPKSNS1
connector to the blue and green cables on the isolation unit for
proper connection and damage. Replace the cables if necessary.
Does the problem remain?
Go to step 9. The problem is
solved.
Step 9
Replace the isolation unit. See
“Isolation unit removal” on
page 371.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
Step 10
Check the red cables connecting the JPKSNS1 connector to the
sensor (input) for proper connection and damage, and replace if
necessary.
Does the problem remain?
Go to step 11. The problem is
solved.
Step 11
Replace the sensor (input). See
“Sensor (input) removal” on
page 341.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
Upper paper path sensors service check
Action Yes No
Step 1
Check the following sensors for proper connection, and reseat if
necessary:
• Sensor (output)
• Sensor (bin full)
Does the problem remain?
Go to step 2. The problem is
solved.
Step 2
Check the sensor cables for proper connection on the sensors and
on the JDSNS1 connector on the controller board.
Are the cables properly connected at both ends?
Go to step 4. Go to step 3.
Step 3
Reconnect the cables.
Does the problem remain?
Go to step 4. The problem is
solved.
5028
Diagnostic information
178

Lexmark C4150 Specifications

General

Drivers included	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	5 s
Time to first page (color, normal)	5.5 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Maximum duty cycle	150000 pages per month
Recommended duty cycle	2000 - 20000 pages per month
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C6, DL
Paper tray media types	Plain paper, Recycled paper, Thin paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Wi-Fi	-
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	3
Maximum internal memory	3072 MB
Sound pressure level (printing)	53 dB
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Power consumption (printing)	- W
Operating altitude	0 - 2896 m
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 80 %

Weight and Dimensions

Depth	497.84 mm
Width	474.98 mm
Height	416.56 mm
